Battery Powered Stage Lights
Created with Pixso.

‌IP65 Waterproof LED Par Up Light 180W RGBWA+UV 6-in-1 DMX-512/RDM 16bit PWM 1000Hz

‌IP65 Waterproof LED Par Up Light 180W RGBWA+UV 6-in-1 DMX-512/RDM 16bit PWM 1000Hz

Brand Name: Wincode Optronics
Model Number: WOP-OPS18
MOQ: 2 pcs
Price: negotiation
Payment Terms: T/T,L/C,Western Union,MoneyGram
Supply Ability: 1000pcs/month
Detail Information
Place of Origin:
Guangdong
Certification:
CE/ROHS
Product Type:
Waterproof Outdoor Led Up Light
Control Mode:
DMX512,RDM
Beam Angle:
25°/45 °/60°
Color Options:
RGBW/RGBAW/RGBAW UV
Other Customize:
12 Leds,18leds
Driver:
Constant Current Driver
Optical Feature:
HDTV Video Flicker Free
Protection Grade:
IP65
Packaging Details:
Exported carton box / flight case
Highlight:

180W LED Par Up Light

,

IP65 Waterproof LED Par Up Light

,

6-in-1 LED Par Up Light

Product Description

IP65 Waterproof LED Par Up Light | 180W RGBWA+UV 6-in-1, DMX-512/RDM, 16bit PWM 1000Hz



‌IP65 Waterproof LED Par Up Light 180W RGBWA+UV 6-in-1 DMX-512/RDM 16bit PWM 1000Hz 0

Product introduction


Unleash Unstoppable Outdoor Brilliance!‌ The ‌IP65 Waterproof LED Par Up Light‌ redefines versatility with ‌18x10W RGBWA+UV

6-in-1 LEDs‌, delivering ‌180W‌ of vibrant, UV-enhanced lighting perfect for dynamic stage shows, architectural washes, or immersive

events. Built to withstand rain, dust, and humidity, its ‌IP65-rated housing‌ ensures flawless performance at festivals, poolside parties,

or industrial installations.

Key Features:
✅ ‌DMX-512/RDM Dual Protocol‌: Seamlessly integrate with lighting consoles for pixel-perfect synchronization.
✅ ‌16bit PWM Dimming at 1000Hz‌: Achieve buttery-smooth transitions and ‌HDTV flicker-free output‌ for broadcast-ready visuals.
✅ ‌Interchangeable Beam Angles (25°/45°/60°)‌: Customize coverage from sharp architectural accents to wide stage washes.
✅ ‌PowerCon In/Out & XLR DMX Ports‌: Simplify daisy-chaining and power distribution in professional setups.

Powered by a ‌32-bit ARM Cortex MCU‌, this light processes commands in real-time while its ‌constant current driver‌ ensures zero

color shift, even after 48+ hours of operation. From grand theaters to rugged outdoor stages, this uplight is your ultimate lighting weapon.


Model No: WOP-OPS18
Light Source: 18*10W (RGBWA+UV 6 in 1)
Lithium Battery: Capacity 12000mAH or 16000mAH customize
Optical: Lens Angle: 35 degrees
Lens Size: 29mm
Control Singal: Protocol: USITTT DMX-512 / RDM
Channel Mode: 4/7 or 5/9 or 6/10 channel
Operating Modes: DMX512, master slave, sound control, auto run, gradient changing, jumping changing
Programs: Preset Colors, Auto Chase Effect, Auto Fade Effect, Customs
Dimmer Mode: Linear Dimmer
PWM Dimming: 16bit Dimming with 1000HZ Frequency
Body Material: Aluminum Die-casting
Power Connector PowerCon AC power In/Out for Indoor
Other Features: Constant Current Driver.
32bit MCU with ARM Cortex.
16bit PWM Dimming
HDTV Video Flicker Free
Working Temperature Monitoring.
Over-temperature Protection.
Fan-less and Quiet Working.
LED Display Menu On/Off.
Sound Active Mode
Preset Colors
Built-in Auto and Fade Program
Warranty: 1-year Limited Warranty
Net Weight: 6Kgs
Display:  1.8"Graphical LCD Touch Screen


‌IP65 Waterproof LED Par Up Light 180W RGBWA+UV 6-in-1 DMX-512/RDM 16bit PWM 1000Hz 1

‌IP65 Waterproof LED Par Up Light 180W RGBWA+UV 6-in-1 DMX-512/RDM 16bit PWM 1000Hz 2

‌IP65 Waterproof LED Par Up Light 180W RGBWA+UV 6-in-1 DMX-512/RDM 16bit PWM 1000Hz 3

‌IP65 Waterproof LED Par Up Light 180W RGBWA+UV 6-in-1 DMX-512/RDM 16bit PWM 1000Hz 4





Applications:


Entertainment: dance halls, night clubs, Wedding, Events, DJ, Disco, club, KTV, pub, bar, family party, dance hall,

theatre, studio, and other entertainment centers …


‌IP65 Waterproof LED Par Up Light 180W RGBWA+UV 6-in-1 DMX-512/RDM 16bit PWM 1000Hz 5


HIGH QUALITY:

All products is made in compliance to CE. RosH UL standards

‌IP65 Waterproof LED Par Up Light 180W RGBWA+UV 6-in-1 DMX-512/RDM 16bit PWM 1000Hz 6


OUR SERVICE:

-OEM,ODM,OBM accepted

-Market analysis in good communication with customers, to make the best plan and develop new products.

-for win-win cooperation.

-Punctual shipping 99.9% so far

-Flexible payment methods: T/T, Western Union, MoneyGram and Paypal etc.


OUR ADVANTAGE:

‌IP65 Waterproof LED Par Up Light 180W RGBWA+UV 6-in-1 DMX-512/RDM 16bit PWM 1000Hz 7

-Products quality is ensured by strict QC from raw materials and products process

-Production team members are experienced in stage lighting assembling

-Our team is able to research and develop new items with professional backups on all aspects.

-Production capacity of 3 containers a month.

-Fast respond to your inquiry within 1 hour from our efficient sales team, so as after-sales issue.

-Our factory stands by a master road while share a wide square, absolutely ready for any sizes container loading.


All products have to go through 4 checks in the workshop:
1. Raw material inspection
2. Assembling inspection
3. Finished products inspection
4. Packing inspection before shipping
