| Place of Origin: | CN |
|---|---|
| Brand Name: | Wincode Optronics |
| Certification: | CE/ROHS |
| Model Number: | WOP-Beam230 |
| Minimum Order Quantity: | 6 pieces |
| Price: | USD $230 - 320 per unit |
| Packaging Details: | Flight case 690*430*880mm(2 in 1) |
| Delivery Time: | 5-8 business days |
| Payment Terms: | T/T, Western Union,and others |
| Supply Ability: | 5000 pieces per month |
| Name: | 7R 230W Beam Moving Head | Model Code: | WOP-Beam230 |
|---|---|---|---|
| Lamp: | YODN, ,Osrm Options | Channel Mode: | 16 CH |
| Control Protocol: | DMX512 | Control Mode:: | DMX512, Master/slave |
Light source: 200W/230W YODN 5R/7R (8000K color temperature,2000 hours)
Pan movement: 540 degrees, 8bit/16bit adjustable, electronic correction
Tilt movement: 280 degrees, 8bit/16bit adjustable, electronic correction
Strobe:double-plate dimming, flash 1-13/s,speed controllable
Color Wheel: 14 colors with two-way rotation and rainbow effect
Gobo Wheel: 17 gobos open, with gobos shaking and arbitrary position function
Rotating prism: 8-facet prism with clockwise and anti-clockwise rotation, prism position function
Optical Device: three lens group, 0°-39° zoom
Power supply: AC110V-250V
Frequency: 50-60Hz
Power consumption: 280W
Dimmer: 0~100% full range dimming
Electronic Focus: 20 meters,5000 LUX
Foggy: 0%-100% linear foggy
Heat protection: one 85℃ over heat protection thermostat
Working temperature: -10℃-45℃ maximum
Control channels: 16 chs
Control mode: DMX512, master/slave
Cooling: low noise fan
Operation menu: LCD screen display
carton packing
Packing size: 535*400*410mm(1 in 1)
N.W: 16kg
G.W: 17.5kg
flight case packing
packing size: 690*430*880mm(2 in 1)
G.W:65kg
| Price term | EXW price |
| Payment terms | TT/Paypal/Western union and others |
| Shipping Way | 1. by Express ( DHL, Fedex, Ups, EMS) 2. by Air 3. by Sea |
| Sample time | 1-3 business days |
| Production time | 5-20 days, but ultimately subject to order quantity |
| Packing | 1. Using EPE packing the goods in case damage 2. Then put it into the Standard carton 3. Flightcase optional |
| Warranty | 1 year |
| After-sell Service | 1.If there is a problem with the product, please describe it and sent the necessary picture or video to us for analyzing. 2. Then we will guide you how to fix it and provide free accessories if needed. 3. For big problem,you can send the products to our factory,then we will send a new one to you! |
stage/disco/KTV/night club//bar, Events -big show/party/wedding,some other kinds entertainment places and so on.
