384 Channels Lighting DMX Controller 485mm X 267 Mm X 85mm Pearl Controller

Basic Information
Place of Origin: Guangdong
Brand Name: Wincode Optronics
Certification: CE/ROHS
Model Number: WOP-MAX384
Minimum Order Quantity: 2 pcs
Price: negotiation
Packaging Details: Exported carton box / flight case
Delivery Time: 3-5 working days after received your payment
Payment Terms: T/T, L/C, Western Union, MoneyGram
Supply Ability: 1000pcs/month
Detail Information
Item: 384 Moving Light DMX Controller Channels: 384 Channels
Standard: DMX512/1990 Maximum Channels Of Fixture: 32 Channels
Fixtures Support: 30 Intelligent Fixtures
High Light:

Led Dmx Controller

,

Dmx512 Light Controller


Product Description

WOP-MAX384 384 Channels Moving Light DMX Controller / Pearl Controller / Tiger Touch Controller





Description:



WOP-MAX384  MAX384 Moving Light DMX Contoller  is one moving head light console with 384 channels, Output port with optical isolated. Up to 30 intelligent Fixtures may be connected with a maximum of 32 channels each. Uses can allocate DMX channel to each intelligent Fixture dynamically.







Specification:



WOP-MAX384 MOVING LIGHT CONTROLLER


DMX512/1990 standard, 384 DMX channels, output with optical isolated.


Up to 30 intelligent Fixtures may be connected with a maximum of 32 channels each.


Uses can allocate DMX channel to each intelligent Fixture dynamically.


The X/Y channel of different intelligent Fixtures can be controlled by modulation Wheel.


Up to 50 SHAPE generators. SHAPE track control is provided to control such effects as circles, lines and shapes like 8,etc.


30 Chases, up to 100 Steps each. Trigger mode selectable: Music synchronously, Auto, Manual speed.


2 Chases, 30 Scenes operated at the same time. At most 30 intelligent Fixtures can be selected simultaneously.


Flash mem-card slot is provided. each Flash mem-card can record the whole data of controller,
LCD display with backlight.


Power supply: AC 90-250V / 50-60Hz


Size: 485mm x 267mm x 85mm



Applications:



Performing arts venues: Stadium (Hall), theater, television, film and television broadcast Office ...
Entertainment: dance halls, night clubs, Wedding, Events, DJ, Disco, club, KTV, pub, bar, family party, dance hall, theatre, studio, casino and other entertainment centers …

384 Channels Lighting DMX Controller 485mm X 267 Mm X 85mm Pearl Controller 0



Wincode Optronics to provide the following professional services:

1. Appearance Designs: concept design--Sketch--Color--3D Modeling--Rendering
2. Structure Designs: Pro/E--Parts--assembly drawing--Prototype
3. Integrated Circuit Design:
4. Software Design:
5. Undertake domestic and international OEM, ODM,manufacturing.

6. Accept customized products order.



Product Show



384 Channels Lighting DMX Controller 485mm X 267 Mm X 85mm Pearl Controller 1
