| Place of Origin: | Guangdong |
|---|---|
| Brand Name: | Wincode Optronics |
| Certification: | CE/ROHS |
| Model Number: | WOP-SuperPro512 |
| Minimum Order Quantity: | 2 pcs |
| Price: | negotiation |
| Packaging Details: | Exported carton box / flight case |
| Delivery Time: | 3-5 working days after received your payment |
| Payment Terms: | T/T, L/C, Western Union, MoneyGram |
| Supply Ability: | 1000pcs/month |
| Item: | 512 Moving Light DMX Controller | Channels: | 512 |
|---|---|---|---|
| Standard: | DMX512/1990 | Fixture Library: | Pearl |
| Fixtures Support: | 62 Intelligent Fixtures | ||
| High Light: | Led Dmx Controller,Dmx Rgb Led Controller |
||
Description:
WOP-SuperPro512 SuperPro 512 Moving Light DMX Contoller is one moving head light console with 512 channels, Output port with optical isolated. Up to 62 intelligent Fixtures may be connected with a maximum of 36 channels each.Uses can allocate DMX channel to each intelligent Fixture dynamically.
Specification:
DMX512/1990 standard, 512 DMX channels, output with optical isolated.
Up to 62 intelligent Fixtures may be connected with a maximum of 36 channels each.
Uses can allocate DMX channel to each intelligent Fixture dynamically.
16-bit X/Y control for absolutely precise movement.
Up to 80 SHAPE generators. SHAPE track control is provided to control such effects as circles, lines and shapes like 8, etc.
62 Chases, up to 100 Steps each. Trigger mode selectable: Music synchronously, Auto, Manual speed
6 Chases, 62 Scenes operated at the same time. At most 62 intelligent Fixtures can be selected simultaneously.
31 MACRO, running combination of different manual, scene and chase can be recorded to the MACRO.
USB port is provided. each USB flask-disk can record the whole data of controller,
LCD display with backlight.
Power supply: AC 90-250V / 50-60Hz
Size: 483mm x 400mm x 105mm
Applications:
Performing arts venues: Stadium (Hall), theater, television, film and television broadcast Office ...
Entertainment: dance halls, night clubs, Wedding, Events, DJ, Disco, club, KTV, pub, bar, family party, dance hall, theatre, studio, casino and other entertainment centers …
Wincode Optronics to provide the following professional services:
1. Appearance Designs: concept design--Sketch--Color--3D Modeling--Rendering
2. Structure Designs: Pro/E--Parts--assembly drawing--Prototype
3. Integrated Circuit Design:
4. Software Design:
5. Undertake domestic and international OEM, ODM,manufacturing.
6. Accept customized products order.
Product Show
